LED Troffer Retrofit Kit, 2x4, 25W/30W/35W, 3500K/4000K/5000K, 4200 Lumens, 120-277 VAC

SKU: SKU:23-RFTF-002

48 in stock

Enjoy additional discounts on orders above $500 at Lumens Depot.

Learn More

$340.00 USD

Sale Sold out

Shipping calculated at checkout.

Quantity

Packs Pack of 4

View full details

Product Description
Product Specification
FAQ

Details

Adjustable Wattage & CCT
This 2×4 LED Panel/Troffer features selectable wattages—25W, 30W, and 35W—along with tunable color temperatures of 3500K, 4000K, and 5000K, allowing users to customize light output and ambiance for any commercial environment.

High Efficiency & Uniform Illumination
With up to 120 lumens per watt and a fully luminous center panel, the fixture delivers bright, uniform, and glare-free illumination—ideal for offices, classrooms, hospitals, and retail spaces.

Smooth 0–10V Dimming
Supports 0–10V dimming for precise light-level adjustments, enhancing comfort, reducing energy use, and accommodating various lighting preferences throughout the day.

Durable, Architectural-Grade Design
The sleek, low-profile construction integrates seamlessly into standard 2×2 and 2×4 grid ceilings, with optional hanging and surface-mount kits for added installation flexibility.

Universal Voltage & Certified Safety
Operating on 120–277 VAC systems, the panel is UL Listed for safety and performance, ensuring long-term reliability. It is engineered for 50,000+ hours of use and backed by a 5-year warranty.

Ideal for Commercial Applications
Perfect for offices, educational facilities, healthcare centers, retail stores, hospitality venues, and commercial lobbies—providing professional-grade, energy-efficient lighting for any setting.

Specifications

Beam angle	110º	Cct	3500K/4000K/5000K
Certification	ETL, UL & DLC©	Chip type	Bridgelux
Color	White	Cri	>80
Dimension	47.76”L x 23.74”W x 2.2”D	Dimmable	0-10V
Efficacy	120lm/w	Frequency	50/60Hz
Housing	Steel sheet and extruded aluminum	Ip rating	IP20
Life hours	50000 Hours	Lumens	4200 Lumens
Operating temperature	-4°F to 104°F	Power factor	[">0.9"]
Size	2ft x 4ft	Voltage	120-277 VAC
Warranty	5 Years	Watt	25W/30W/35W
Diffuser	Frosted Polystyrene	Operating humidity	Damp Location

Downloads

Installation Guide Installation Guide

FAQS

What is a troffer retrofit kit?

A troffer retrofit kit upgrades existing fluorescent troffer fixtures to energy-efficient LED lighting without replacing the entire housing.

Will this retrofit kit fit standard 2x4 troffers?

Yes, it is designed to fit most standard 2x4 recessed troffer fixtures commonly found in commercial buildings.

Can I adjust the brightness level?

Yes, selectable wattage settings of 25W, 30W, and 35W allow you to customize light output for your space.

What color temperatures are available?

You can choose between 3500K, 4000K, and 5000K to match your lighting preference and application.

How bright is this retrofit kit?

The fixture delivers up to 4,200 lumens, providing efficient and uniform illumination for commercial environments.

Why choose a retrofit kit instead of a new fixture?

Retrofit kits help reduce installation costs and labor by utilizing your existing troffer housing.

Is this suitable for office renovations?

Yes, it's an excellent solution for upgrading outdated fluorescent lighting in offices, schools, hospitals, and retail spaces.

Does this retrofit kit operate on commercial voltage?

Yes, it supports 120-277VAC, making it compatible with most commercial electrical systems.

Will this help lower energy consumption?

Yes, LED technology consumes significantly less energy than traditional fluorescent systems while maintaining excellent brightness.

Does the retrofit kit provide even light distribution?

Yes, the diffuser design helps eliminate dark spots and creates smooth, consistent illumination across the space.
